Pipehorn 800-H Pipe and Cable Locator

$1,390.00

The Pipehorn 800-H is our single frequency model and the perfect addition to your locating arsenal.  It’s superior high frequency (480 kHz) performance helps you clear dig sites and locate utilities other tools struggle to light up.

We recommend hooking-up to utilities, but when direct connection is not possible, the Pipehorn 800-H is the best tool in the industry to find even the toughest conductors: coated iron pipes with insulated joints, unenergized power (street/parking lot lights), worn-out tracer tape & wire, short side services & stub-outs, concentric neutrals, and fiber. Nothing sweeps areas for un-marked utilities like a Pipehorn.

For those looking to have a single, yet simple locator on their truck that covers all the bases, take a look at the Pipehorn 800-HL.

Specifications:
Transmitter:
High Frequency (480 kHz)
Modes: Inductive, Conductive, Signal Clamp
Batteries:  Eight C  Alkaline included
Weight: 3.3 lbs

Receiver:
Output: Instantaneous, audible from built-in speaker, visual from fast response meter
Sensitivity: Smart Control (semi automatic)
Batteries: Two 9 volt Alkaline included
Unit Weight: 3.4 lbs

Warranty:
3 Years

800-H High Frequency Locator – Manual

800 Series Locators – Quick Guide

800 Series Series Locators – Datasheet
